Hikrobot MV-ID5060M-12S-WBN Smart Code Reader

Name: Hikrobot MV-ID5060M-12S-WBN Smart Code Reader
Brand: Hikrobot
SKU: VS-1011
Availability: InStock

Hikrobot ID5000 Serisi Akıllı Kod Okuyucu

Hikrobot MV-ID5060M-12S-WBN Smart Code Reader

Hikrobot Smart Code Reader kategorisine ait ürünümüzün özellikleri:

Kodları etkili bir şekilde okumak için yerleşik derin öğrenme algoritmasını benimser.
Otomatik odaklama işlevi sunmak için mekanik otomatik odaklama lensini kullanır.
Giriş ve çıkış sinyalleri için çoklu IO arabirimlerini destekler.
Farklı iletişim protokollerini destekler, örneğin TCP, Seri, FTP, Profinet vb.
Yüksek kaliteli görüntü verilerini elde etmek ve sunmak için CMOS sensörünü kullanır.
RS-232 seri portunu içerir ve cihaz durumunu gösteren göstergelere sahiptir.

3D Çizimler

Katalog

Kullanım Kılavuzu

Endüstriyel Protokol

Ürün Özellikleri

Seriler

Ölçüler

Software

Model	Product Model	MV-ID5060M-12S-WBN
Model	Type	12mm Mechanical Autofocus lens 6MP Allfunction Industrial Code Reader
Performance	Symbologies	1-dimensional codes: Code 39, Code 93, Code 128, CodaBar, EAN 8, EAN 13, UPCA, UPCE, ITF 14, ITF 25, Matrix 25, MSI, China Post, Code 11 2-dimensional codes: QR Code, Data Matrix Stack codes: PDF 417
	Max. frame rate	30 fps
	Max. reading speed	90 codes/sec
	Sensor type	CMOS, rolling shutter
	Pixel size	2.4 µm × 2.4 µm
	Sensor size	1/1.8″
	Resolution	3072 × 2048
	Exposure time	16 μs to 1 sec
	Gain	0 dB to 40 dB
	Mono/color	Mono
	Communication protocol	SmartSDK, TCP Client, Serial, FTP, TCP Server, Profinet, Ethernet/IP, MELSEC, Fins, ModBus, SLMP, UDP
Electrical feature	Data interface	GigE
	Digital I/O	12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 3/4/5) × 3, RS-232 input × 1, and RS-232 output × 1.
	Power supply	24 VDC
	Max. power consumption	Approx. 23 W@24 VDC (light source is enabled)
Mechanical	Focal length	12 mm (0.5″)
	Lens mount	M12-mount, mechanical autofocus lens.
	Lens cap	Transparent lens cap. Polarization lens cap is optional.
	Light source	White light. Red or blue light is optional.
	Indicator	Power indicator (PWR), network indicator (LNK/ACT), and user-defined indicator (U1/U2).
	Dimension	118.7 mm × 78 mm × 73.2 mm (4.7″ × 3.1″ × 2.9″)
	Weight	Approx. 520 g (1.1 lb.)
	Ingress protection	IP67 (under proper installation of waterproof lens cap)
	Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
	Humidity	20% to 95% RH, non-condensing
General	Client software	IDMVS
General	Certification	CE, FCC, RoHS, KC

Hikrobot MV-ID5200PM-00C-NNN(V2.0) Smart Code Reader Hikrobot MV-ID5200M-00C-NNN Smart Code Reader Hikrobot MV-ID5120M-00C-NNN Smart Code Reader Hikrobot MV-ID5060M-00C-NNN Smart Code Reader Hikrobot MV-ID5060M-00C-WBN Smart Code Reader Hikrobot MV-ID5060M-25S-WBN Smart Code Reader Hikrobot MV-ID5060M-16S-WBN Smart Code Reader Hikrobot MV-ID5060M-08S-WBN Smart Code Reader Hikrobot MV-ID5050M-25S-WBN Smart Code Reader Hikrobot MV-ID5050M-16S-WBN Smart Code Reader Hikrobot MV-ID5050M-12S-WBN Smart Code Reader Hikrobot MV-ID5050M-08S-WBN Smart Code Reader Hikrobot MV-ID5030M-25S-WBN Smart Code Reader Hikrobot MV-ID5030M-16S-WBN Smart Code Reader Hikrobot MV-ID5030M-12S-WBN Smart Code Reader Hikrobot MV-ID5030M-08S-WBN Smart Code Reader Hikrobot MV-ID5060M-12S-WBN Smart Code Reader

Machine Vision Software IDMVS V4.2.3

Windows

Client

638.54 MB

İndir
