Hikrobot MV-CI003-GL-N15 Area Scan Camera

Name: Hikrobot MV-CI003-GL-N15 Area Scan Camera
Brand: Hikrobot
SKU: VS-5100
Availability: InStock

Hikrobot CI Area Scan Camera

Hikrobot MV-CI003-GL-N15 Area Scan Camera

Hikrobot CI Area Scan Camera kategorisine ait ürünümüzün özellikleri:

0,3 MP çözünürlüğe sahip yüksek hassasiyetli vanadyum oksit soğutmasız dedektör kullanır.
Çoklu palet modlarını, gri tonlama algılamayı, görüntü ayarlamayı vb. destekler.
4 taraftan esnek montaj için panellerde montaj delikleri bulunan kompakt tasarım. GigE arayüzünü kullanır ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
GigE Vision V2.0 Protokolü ve GenlCam Standardı ile uyumludur.

3D Çizimler

Katalog

Kullanım Kılavuzu

Ürün Özellikleri

Seriler

Ölçüler

Software

Model	Product Model	MV-CB004-10GM-S
Model	Type	0.4MP Board Level Camera, GigE,IMX297,Mono,M12-mout
Performance	Sensor type	CMOS, global shutter
	Sensor model	Sony® IMX297
	Pixel size	6.9 μm × 6.9 μm
	Sensor size	1/2.9″
	Resolution	720 × 540
	Max. frame rate	125.2 fps @720 × 540
	Dynamic range	74 dB
	SNR	41 dB
	Gain	0 dB to 24 dB
	Exposure time	UltraShort exposure mode: 1 μs to 14 μs Standard exposure mode: 15 μs to 10 sec
	Exposure mode	Off/ Once/ Continuous exposure mode
	Mono/color	Mono
	Pixel format	Mono 8/10/10p/12/12p
	Binning	Supports 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4
	Decimation	Supports 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4
	Reverse image	Supports horizontal and vertical reverse image output
Electrical feature	Data interface	Gigabit Ethernet, compatible with Fast Ethernet
	Digital I/O	6-pin connector provides power and I/O, including non-isolated input × 1 (Line 0), non-isolated output × 1 (Line 1), and bi-directional non-isolated I/O × 1 (Line 2).
	Power supply	9 VDC to 24 VDC, supports PoE
	Power consumption	Typ. 2.5 W@12 VDC
Mechanical	Lens mount	M12-mount
	Dimension	29 mm × 29 mm × 30.2 mm (1.1″ × 1.1″ × 1.2″)
	Weight	Approx. 45 g (0.1 lb.)
	Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
	Humidity	20% to 80% RH, non-condensing
General	Client software	MVS or third-party software meeting with GigE Vision Protocol
	Operating system	32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS
	Compatibility	GigE Vision V2.0, GenICam
	Certification	CE, FCC, RoHS, KC
