Hikrobot MV-CE050-31GC Area Scan Camera

Name: Hikrobot MV-CE050-31GC Area Scan Camera
Brand: Hikrobot
SKU: VS-5208
Availability: InStock

Hikrobot CE Area Scan Camera

Hikrobot MV-CE050-31GC Area Scan Camera

Hikrobot CE Area Scan Camera kategorisine ait ürünümüzün özellikleri:

GigE arayüzünü benimser ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
Seri iletim ve yeniden iletim için 128 MB’a kadar yerel bellek. Otomatik pozlama kontrolü, LUT, Gama düzeltmesi vb. destekler.
Donanım tetikleme, yazılım tetikleme vb. destekler.
GigE Vision V2.0 Protokolü, GenlCam Standardı ve protokol ve standarda dayalı üçüncü taraf yazılımlarla uyumludur.

3D Çizimler

Katalog

Kullanım Kılavuzu

Ürün Özellikleri

Seriler

Ölçüler

Software

Model	Product Model	MV-CE050-31GC
Model	Type	5MP Area Scan Camera, GigE,AR0521,Color
Performance	Sensor type	CMOS, rolling shutter
	Sensor model	Aptina AR0521
	Pixel size	2.2 μm × 2.2 μm
	Sensor size	1/2.5″
	Resolution	2592 × 1944
	Max. frame rate	24 fps @ 2592 × 1944
	Dynamic range	63 dB
	SNR	37 dB
	Gain	0 dB to 23 dB
	Exposure time	21 μs to 1 sec
	Exposure mode	Off/Once/Continuous exposure mode
	Mono	Color
	Pixel format	Mono 8/10/12, Bayer GB 8/10/10p/12/12p, YUV422Packed, YUV422_YUYV_Packed, BGR 8, RGB 8
	Binning	Supports 1 × 1, 2 × 2, 4 × 4
	Decimation	Supports 1 × 1, 2 × 2, 4 × 4
	Reverse image	Supports horizontal and vertical reverse image output
	Image buffer	128 MB
Electrical feature	Data interface	Gigabit Ethernet, compatible with Fast Ethernet
	Digital I/O	6-pin Hirose connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
	Power supply	9 VDC to 24 VDC, supports PoE
	Power consumption	Typ. 2.4 W @ 12 VDC
Mechanical	Lens mount	C-mount
	Dimension	29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″)
	Weight	Approx. 68 g (0.15 lb.)
	Ingress protection	IP30 (under proper lens installation and wiring)
	Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
	Humidity	20% RH to 80% RH (no condensation)
General	Client software	MVS or third-party software meeting with GigE Vision Protocol
	Operating system	32/64-bit Windows 7/10, 32/64-bit Linux
	Compatibility	GigE Vision V2.0, GenlCam
	Certification	CE, RoHS, KC
