Hikrobot MV-CA050-20GM Area Scan Camera

Name: Hikrobot MV-CA050-20GM Area Scan Camera
Brand: Hikrobot
SKU: VS-5510
Availability: InStock

Hikrobot CA Area Scan Camera

Hikrobot MV-CA050-20GM Area Scan Camera

Hikrobot CA Area Scan Camera kategorisine ait ürünümüzün özellikleri:

GigE arayüzünü kullanır ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
Seri iletim ve yeniden iletim için 128 MB’a kadar yerel bellek.
Otomatik pozlama kontrolü, LUT, Gama düzeltmesi vb. destekler.
Donanım tetikleme, yazılım tetikleme vb. destekler.
GigE Vision V1.2 Protokolü ve protokole dayalı üçüncü taraf yazılımlarla uyumludur.

3D Çizimler

Katalog

Kullanım Kılavuzu

Ürün Özellikleri

Seriler

Ölçüler

Software

Model	Product Model	MV-CA050-20GM
Model	Type	5MP Area Scan Camera, GigE,PYTHON5000,Mono
Performance	Sensor type	CMOS, global shutter
	Sensor model	PYTHON5000
	Pixel size	4.8 μm × 4.8 μm
	Sensor size	1″
	Resolution	2592 × 2048
	Max. frame rate	22 fps @ 2592 × 2048
	Dynamic range	57.5 dB
	SNR	39.5 dB
	Gain	0 dB to 15 dB
	Exposure time	65 μs to 10 sec
	Exposure mode	Off/Once/Continuous exposure mode
	Mono	Mono
	Pixel format	Mono 8/10/10p/12/12p
	Binning	Supports 1 × 1, 1 × 2, 2 × 1, 1 × 4, 4 × 1, 2 × 2, 2 × 4, 4 × 2, 4 × 4
	Decimation	Supports 1 × 1, 2 × 2
	Reverse image	Supports horizontal and vertical reverse image output
	Image buffer	128 MB
Electrical feature	Data interface	Gigabit Ethernet, compatible with Fast Ethernet
	Digital I/O	6-pin Hirose connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
	Power supply	12 VDC, supports PoE
	Power consumption	Typ. 3.3 W @ 12 VDC
Mechanical	Lens mount	C-mount
	Dimension	29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″)
	Weight	Approx. 68 g (0.15 lb.)
	Ingress protection	IP30 (under proper lens installation and wiring)
	Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
	Humidity	20% RH to 80% RH (no condensation)
General	Client software	MVS or third-party software meeting with GigE Vision Protocol
	Operating system	32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux
	Compatibility	GigE Vision V1.2, GenICam
	Certification	CE, RoHS, KC
