Hikrobot MV-CU050-30GM Area Scan Camera

Hikrobot CU Area Scan Camera

Hikrobot CU Area Scan Camera kategorisine ait ürünümüzün özellikleri:

Düşük güç tüketimi tasarımı ve istikrarlı performans sunar.
Kazanç, pozlama süresi vb. ayarların otomatik ve manuel olarak yapılmasını destekler.
Donanım tetikleme, yazılım tetikleme, serbest çalışma vb. özelliklerini destekler.
GigE arayüzünü kullanır ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
GigE Vision V2.0 Protokolü, GenlCam Standardı ve protokol ve standarda dayalı üçüncü taraf yazılımlarla uyumludur.

Ürün Özellikleri

Seriler

Ölçüler

Software

Model	Product Model	MV-CU050-30GM
Model	Type	5MP Area Scan Camera, GigE, AR0521, Mono
Performance	Sensor type	CMOS, rolling shutter
	Sensor model	AR0521
	Pixel size	2.2 μm × 2.2 μm
	Sensor size	1/2.5″
	Resolution	2592 × 1944
	Max. frame rate	24 fps @ 2592 × 1944 Mono 8
	Dynamic range	63 dB
	SNR	37 dB
	Gain	0 dB to 15 dB
	Exposure time	21 μs to 1 sec
	Exposure mode	Off/Once/Continuous exposure mode
	Mono/color	Mono
	Pixel format	Mono 8/10/10Packed/12/12Packed
	Binning	Supports 1 × 1, 2 × 2
	Decimation	Supports 1 × 1, 2 × 2
	Reverse image	Supports horizontal and vertical reverse image output
Electrical feature	Data interface	Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
	Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
	Power supply	9 VDC to 24 VDC, supports PoE
	Power consumption	Typ. 1.78 W @ 12 VDC
Mechanical	Lens mount	C-mount
	Dimension	29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″)
	Weight	Approx. 100 g (0.2 lb.)
	Ingress protection	IP30 (under proper lens installation and wiring)
	Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
	Humidity	20% RH to 80% RH (no condensation)
General	Client software	MVS or third-party software meeting with GigE Vision Protocol
	Operating system	32/64-bit Windows XP/7/10/11, 32/64-bit Linux, and 64-bit MacOS
	Compatibility	GigE Vision V2.0, GenICam
	Certification	RoHS
