Hikrobot MV-CU200-20GC Area Scan Camera

Name: Hikrobot MV-CU200-20GC Area Scan Camera
Brand: Hikrobot
SKU: VS-4349
Availability: InStock

Hikrobot CU Area Scan Camera

Hikrobot MV-CU200-20GC Area Scan Camera

Hikrobot CU Area Scan Camera kategorisine ait ürünümüzün özellikleri:

Düşük güç tüketimi tasarımı ve istikrarlı performans sunar.
Kazanç, pozlama süresi vb. ayarların otomatik ve manuel olarak yapılmasını destekler.
Donanım tetikleme, yazılım tetikleme, serbest çalışma vb. özelliklerini destekler.
GigE arayüzünü kullanır ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
GigE Vision V2.0 Protokolü, GenlCam Standardı ve protokol ve standarda dayalı üçüncü taraf yazılımlarla uyumludur.

3D Çizimler

Katalog

Kullanım Kılavuzu

Ürün Özellikleri

Seriler

Ölçüler

Software

Model	Product Model	MV-CU200-20GC
Model	Type	20MP Area Scan Camera, GigE, AR2020, Color
Performance	Sensor type	CMOS, rolling shutter
	Sensor model	AR2020
	Pixel size	1.4 μm × 1.4 μm
	Sensor size	1/1.8″
	Resolution	5120 × 3840
	Max. frame rate	5.9 fps @ 5120 × 3840 Bayer GR 8
	Dynamic range	60 dB
	SNR	39 dB
	Gain	0 dB to 48 dB
	Exposure time	53 μs to 10 sec
	Exposure mode	Off/Once/Continuous exposure mode
	Mono/color	Color
	Pixel format	Bayer GR 8/10/10 Packed/12/12 Packed
	Binning	Supports 1 × 1, 2 × 2
	Decimation	Not supported
	Reverse image	Supports horizontal and vertical reverse image output
Electrical feature	Data interface	Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
	Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
	Power supply	9 VDC to 24 VDC; PoE is optional
	Power consumption	Typ. 2.0 W @ 12 VDC
Mechanical	Lens mount	C-mount
	Dimension (without lens)	29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″)
	Weight	Approx. 100 g (0.2 lb.)
	Ingress protection	IP30 (under proper lens installation and wiring)
	Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
	Humidity	20% RH to 95% RH, no condensation
General	Client software	MVS or third-party software meeting with GigE Vision Protocol
	Operating system	32/64-bit Windows XP/7/10/11, 32/64-bit Linux and 64-bit MacOS
	Compatibility	GigE Vision V2.0, GenICam
	Certification	CE, RoHS, KC
