Hikrobot MV-CH050-10UC Area Scan Camera

Hikrobot CH Area Scan Camera kategorisine ait ürünümüzün özellikleri:

  • 4 taraftan esnek montaj için panellerde montaj delikleri bulunan kompakt tasarım.
  • LSC, Sequencer, Super Palette vb. destekler. Özelleştirilmiş ROI, yatay ve dikey ters görüntü çıktısını destekler.
  • USB3 Vision Protokolü, GenlCam Standardı ve bu protokol ve standartlara dayalı üçüncü taraf yazılımlarla uyumludur.

Katalog PDF İndir Katalog Kullanım Kılavuzu PDF İndir Kullanım Kılavuzu
Ürün Özellikleri
Seriler
Ölçüler
Software
Model Product Model MV-CH050-10UC
Type 5MP Area Scan Camera, USB3, IMX250, Color, V4
Performance Sensor type CMOS, global shutter
Sensor model Sony® IMX250
Pixel size 3.45 μm × 3.45 μm
Sensor size 2/3″
Resolution 2448 × 2048
Max. frame rate 74.1 fps @2448 × 2048 Bayer RG 8
Dynamic range 71 dB
SNR 40 dB
Gain 0 dB to 24 dB
Exposure time UltraShort exposure mode: 1 μs to 14 μs Standard exposure mode: 15 μs to 10 sec
Mono/color Color
Exposure mode Off/Once/Continuous exposure mode
Pixel format Mono 8/10/12, Bayer RG 8/10//10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed, RGB 8, BGR 8
Binning Supports 1 × 1, 2 × 2, 4 × 4
Decimation Supports 1 × 1, 2 × 2
Reverse image Supports horizontal and vertical reverse image output
Electrical feature Data interface USB3.0, compatible with USB2.0
Digital I/O 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Power supply 9 VDC to 24 VDC, supports USB3.0 power supply
Power consumption Typ. 2.8 W@5 VDC (USB3.0 provides power supply)
Mechanical Lens mount C-mount
Dimension 29 mm × 29 mm × 30 mm (1.1″ × 1.1″ × 1.2″)
Weight Approx. 80 g (0.2 lb.)
Ingress protection IP40 (under proper lens installation and wiring)
Temperature Working temperature: –10 °C to 50 °C (14 °F to 122 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity 20% RH to 95% RH (no condensation)
General Client software MVS or third-party software meeting with USB3 Vision Protocol
Operating system 32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux
Compatibility USB3 Vision, GenICam
Certification CE, RoHS, KC
