Hikrobot MV-CH160-60GM Area Scan Camera
Hikrobot CH Area Scan Camera kategorisine ait ürünümüzün özellikleri:
- 4000 × 4000 çözünürlük, 3,2 µm × 3,2 µm piksel boyutu.
- GigE arayüzünü kullanır ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
- Üst ve alt panellerinde montaj delikleri bulunan kolay ve esnek kurulum.
- GigE Vision V2.0 Protokolü, GenlCam Standardı ve protokol ve standarda dayalı üçüncü taraf yazılımlarla uyumludur.
Ürün Özellikleri
Seriler
Ölçüler
Software
| Model | Product Model | MV-CH160-60GM |
| Type | 16MP Area Scan Camera, GigE | |
| Performance | Sensor type | CMOS, global shutter |
| Sensor model | HK | |
| Pixel size | 3.2 μm × 3.2 μm | |
| Sensor size | 1.1″ | |
| Resolution | 4000 × 4000 | |
| Max. frame rate | 7.25 fps @ 4000 × 4000 | |
| Dynamic range | 65 dB | |
| SNR | 38 dB | |
| Gain | 6 dB to 14 dB | |
| Exposure time | 12 μs to 10 sec | |
| Exposure mode | Off/Once/Continuous exposure mode | |
| Mono/color | Mono | |
| Pixel format | Mono 8/10/12 | |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 | |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 | |
| Reverse image | Supports horizontal and vertical reverse image output | |
| Electrical feature | Data interface | Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s) |
| Digital I/O | 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). | |
| Power supply | 9 VDC to 26 VDC, supports PoE | |
| Power consumption | Typ. 3.72 W @ 12 VDC | |
| Mechanical | Lens mount | C-mount |
| Dimension | 29 mm × 44 mm × 59 mm (1.1″ × 1.7″ × 2.3″) | |
| Weight | Approx. 100 g (0.2 lb.) | |
| Ingress protection | IP30 (under proper lens installation and wiring) | |
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) | |
| Humidity | 20% RH to 80% RH (no condensation) | |
| General | Client software | MVS or third-party software meeting with GigE Vision Protocol |
| Operating system | 32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux | |
| Compatibility | GigE Vision V2.0, GenlCam | |
| Certification | CE, RoHS, KC |
