Hikrobot CH Area Scan Camera

Hikrobot MV-CH120-20GM Area Scan Camera

Hikrobot CH Area Scan Camera kategorisine ait ürünümüzün özellikleri:

  • Kazanç ve pozlama süresi için otomatik veya manuel ayarlamayı ve LUT ve Gama düzeltmesi için manuel ayarlamayı destekler.
  • LSC, sıralayıcı, pasif iletim vb. özellikleri destekler.
  • Renkli kamera beyaz dengesi, CCM, Süper Palet, Süper Bayer vb. özellikleri destekler.
  • GigE arayüzünü benimser ve röle olmadan maksimum 100 metre iletim mesafesine sahiptir.
  • 4 taraftan esnek montaj için panellerde montaj delikleri bulunan kompakt tasarım.
  • GigE Vision V2.0 Protokolü, GenlCam Standardı ve protokol ve standarda dayalı üçüncü taraf yazılımlarla uyumludur.

Katalog PDF İndir Katalog Kullanım Kılavuzu PDF İndir Kullanım Kılavuzu
Ürün Özellikleri
Seriler
Ölçüler
Software
Model Product Model MV-CH120-20GM
Type 12MP Area Scan Camera, GigE, XGS12000, Mono, V4
Performance Sensor type CMOS, global shutter
Sensor model OnSemi XGS12000
Pixel size 3.2 μm × 3.2 μm
Sensor size 1″
Resolution 4096 × 3072
Max. frame rate 9.6 fps @ 4096 × 3072 Mono 8
Dynamic range 66.4 dB
SNR 40 dB
Gain 0 dB to 18 dB
Exposure time UltraShort exposure mode: 52 μs to 161 μs Standard exposure mode: 162 μs to 10 sec
Exposure mode Off/Once/Continuous exposure mode
Mono/color Mono
Pixel format Mono 8/10/10Packed/12/12Packed
Binning Supports 1 × 1, 2 × 2, 4 × 4
Decimation Supports 1 × 1, 2 × 2, 4 × 4
Reverse image Supports horizontal and vertical reverse image output
Electrical feature Data interface Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Digital I/O 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Power supply 9 VDC to 24 VDC, supports PoE
Power consumption Typ. 2.6 W @ 12 VDC
Mechanical Lens mount C-mount
Dimension 29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″)
Weight Approx. 100 g (0.2 lb.)
Ingress protection IP40 (under proper lens installation and wiring)
Temperature Working temperature: –10 °C to 50 °C (14 °F to 122 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity 20% RH to 95% RH (no condensation)
General Client software MVS or third-party software meeting with GigE Vision Protocol
Operating system 32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux
Compatibility GigE Vision 2.0, GenlCam
Certification CE, RoHS, KC
